4 Side Sealing&Packaging Machine
Oral Dissolving Film Cartoning Machine
PPD-CM150
Oral dissolving film cartoning machine is an automated two-stage packaging system that packs individually packaged oral dissolving film (ODF) bags or boxes into cartons for final distribution. This machine is an important component of a complete ODF production line, located after the primary packaging process.Products are manually fed onto the synchronous belt trough at the front of the cartoning machine. When photoelectric sensors detect the product passing through the machine, mechanical principles drive the machine to progressively complete all functions: unloading, opening, forming, pushing, packing, earing, folding, tongue insertion, and final shaping. The entire cartoning process is then complete.
Features:
1. The cartons need to be pre-folded by the carton supplier.
2. The carton ears need to be rounded.
3. There must be no glue leakage inside the carton.
Process Flow:
Feeding --- Box Unloading --- Box Opening --- Forming --- Pushing --- Page Printing --- Tongue Insertion --- Complete Box Packaging
Main Data:
Name: Oral Dissolving Film Cartoning Machine
Model: PPD-CM150
Carton Dimensions: Length 110 * Width 70 * Height 20mm
Paper Quality Requirements: 300g/m² ≤ Ideal for: 350g/m² ≤ 450g/m²
Other Carton Requirements: Creasing depth not less than 0.4mm, with pre-folding effect
Cartoning Capacity (boxes/minute): 40-50 boxes/minute
Voltag:220V,50hz
Power:1.5kw
