4 Side Sealing&Packaging Machine
Hard Blister Packaging Machine
PPD-HBPM260
Hard blister packaging machine is a highly automated piece of packaging equipment that seals products between a transparent plastic blister and a backing layer of aluminum foil or cardboard. It offers excellent sealing integrity and moisture resistance, making the packaged products convenient to carry.Features:
1. Fully automated packaging process featuring photoelectric alignment correction to ensure clean, burr-free edges.
2. The machine is user-friendly and controlled via a PLC touchscreen interface; packaging temperature and speed can be adjusted to suit the specific packaging materials, product thickness, and length. Driven by a servo motor and integrated photoelectric-pneumatic controls, the system features self-diagnostic capabilities for troubleshooting. The display is clear and intuitive, and the operating system interface supports a wide range of local languages, including Spanish, French, Korean, Russian, Japanese, and Arabic.
3. The entire machine is clad in stainless steel, offering an aesthetically pleasing appearance while ensuring ease of cleaning and long-term durability. It also boasts low operating and maintenance costs.
Main Technical Data:
Name:Hard Blister Packaging Machine
Model:PPD-HBPM260
Max. Forming Area:250 x 180mm
Punching Frequency:12–15 (strokes/min)
Max. Forming Area & Depth:0–180 (Precision Lead Screw Traction)
Stroke Range:80x57mm
PVC Rigid Sheet:0.15–0.5 x 260mm
PTP Aluminum Foil:0.02–0.035x 260mm
Dialysis Paper:50–100gx260mm
Power:1.5kw
Voltage:380V,50Hz
