4 Side Sealing&Packaging Machine
Oral Dissolving Strips Of Dietary Supplements Sleep Strips ODF OTF Manufacturing Machine
PPD-OTFM-320
Oral dissolving strips of dietary supplements sleep strips odf otf manufacturing machine is used to manufacture oral dissolving film products that can quickly dissolve in the mouth. Firstly, the material is mixed with the film-forming material and solvent in a specific proportion, and then stirred and heated to form a uniform coating solution. Then, the coating system, the coating solution is evenly coated on the release film substrate, and the film thickness and uniformity are precisely controlled. Subsequently, the coated film sent into the drying room to quickly evaporate the solvent and solidify the film.The dried ODF film roll through a special packaging machine,online cut and pack into bags to make independent small packages which are easy to carry.
Features:
1. Online longitudinal slitting and rewinding, capable of splitting into 2-3 rolls.
2. Servo-driven bottom paper (film) traction ensures high precision and stable operation.
3. Adaptive slip-type film rewinding ensures stable tension for both large and small rolls and simple operation.
4. Independent oven with adjustable temperature control.
Main Data:
Name:Oral Dissolving Strips Of Dietary Supplements Sleep Strips ODF OTF Manufacturing Machine
Model:PPD-OTFM-320
Coating width: max320mm
Coating thickness:0.02mm to 0.1mm( Adjustable)
Coating speed: 0.01-1m/min (depending on product)
Base film: 350mm,OD ≤ 350mm, ID: 76mm
Voltage: 220V 50Hz
Power: 12kw
Air supply: 0.6-0.8Mpa
