Alcohol Pad Machine
High Speed 8 Lanes Alcohol Prep Pad Packaging Machine
PPD-8L1000
High speed 8 lanes alcohol prep pad packaging machine is our latest design to pack small-package with four-side sealing packaging of alcohol prep pad,alcohol pad,alcohol swabs,BZK antiseptic swabs,povidone iodine prep pad,cleansing pad,alcohol wipes etc.We have different model,such as 2 lanes model,4 lanes model,6 lanes model,8 lanes for option.
Features:
1. Color touch screen operation, servo motor system,PLC programmable controller intelligently controls the operation of the whole machine, simple in operation.
2.Four side sealing bag, 8 row bag making, under the premise of high liquid volume, the sealing is tight, no leakage, no foaming, and the sealing is smooth and beautiful.
3.Machine adopts high-sensitivity cursor electric eye to accurately track and locate the film color block for precise film feeding.
Main Data:
Name:High Speed 8 Lanes Alcohol Prep Pad Packaging Machine
Model:PPD-8L1000
Nonwoven unfolded size:60*30mm
Nonwoven folded size:30*30mm
Packaging size:50*50mm
Folding method:nonwoven cloth folded one time,two layers
Processing ability:500-1000pc/min
Suitable nonwoven fabric: 30-60gsm,spunlace nonwoven fabric,diameter≤600mm, width 60mm
Suitable packing film: 73-106gsm,aluminum foil paper.compsited film, width:800mm
Raw material paper core size:3inch
Voltage:380V ,50hz
Power:5.5kw
NOTE:Different sizes can be customzied.
